Mobile Phone Mainboard
Craft show
| Layers | 10L |
| Product mix | 2+6+2 |
| Board thickness | 0.7mm |
| Material | EM-285 |
| Line width / space | 0.05/0.05mm |
| Minimum laser drilling aperture | 0.1mm |
| Surface treatment | Sink gold+OSP |
Craft show
| Layers | 10L |
| Product mix | 2+6+2 |
| Board thickness | 0.7mm |
| Material | EM-285 |
| Line width / space | 0.05/0.05mm |
| Minimum laser drilling aperture | 0.1mm |
| Surface treatment | Sink gold+OSP |
Craft show
| Layers | 12L Anylayer |
| Material | EM-390 Halogen-Free |
| Thickness | 0.8±0.08 mm |
| Line width / space | 0.04/0.05mm |
| Laser hole size | 0.075mm |
| Surface treatment | ENIG + OSP |
Craft show
| Layers | 12L BU5 5(Anylayer) |
| Material | EM-526 |
| Thickness | 0.94+/-0.10mm |
| Line width / space | 0.05/0.05mm |
| Min aperture | 0.1mm |
| Surface treatment | ENIG |
Craft show
| Layers | 10L(2+6+2） |
| Material | NY-3170M |
| Thickness | 0.8mm |
| Line width / space | 0.06/0.06mm |
| Laser hole size | 0.1mm |
| Surface treatment | OSP |
Craft show
| Layers | 12L( 4+4+4) |
| Board thickness | 1.2+/-0.12mm |
| Material | EM-390 |
| Line width / space | 0.06/0.06mm |
| Laser Aperture | 0.1mm |
| Surface treatment | ENIG |
